PrimeFilm XA Plus
▪ Auto 135 Roll Film & Filmstrip Scanning
▪ Manual 135 Slide Scanning
▪ Auto Focus
▪ 10,000 dpi / True Color
▪ Optimal Brightness - Auto Exposure
▪ IR Dust/Scratch Removal - Magic Touch
▪ HDR - Multipass Xposure
▪ Color Reconstruction - Auto Color
▪ Noise Reduction
▪ Support DNG format
▪ Support Mac/Windows
A comprehensive solution especially tailored for 35mm film rolls, ideal for photographers, hobbyists, and digital imaging shop
- Advanced Design - The most recent release from Pacfic Image Electronics, the PrimeFilm XA Plus scanner, is designed for digitizing 35mm film rolls and slides. Its advanced optical system ensures high detail even in shadowed areas and offers an impressive tonal range. With its built-in Infrared dust and scratch removal – MagicTouch, users can effectively remove dust and scratches from original negatives and slides without requiring additional post-processing.
- Auto Focus - The XA Plus scanner features an auto focus capability, utilizing a built-in automatic lifted platform at the front of the device. This hardware design enables automatic focus adjustment, ensuring optimal sharpness for scanned images.
- Auto roll film & film strip scanning - The PrimeFilm XA Plus scanner offers automatic roll film and film strip scanning through its innovative auto film feeder feature. This allows users to continuously insert film strips and rolls, facilitating the scanning of up to 40 frames in one go.
- Pacific Image Exclusive Software Included - CyberView X - Includes Magic Touch for dust removal, precise color adjustment, and support for DNG file format, etc., offering extensive post-processing options while preserving image quality.
PrimeFilm XA Plus has an auto-focus feature, which automatically adjusts focus for optimal clarity, offering higher color saturation for more natural-looking images. Additionally, it has an unique automatic film feeding technology, users can continuously insert film strips and rolls, allowing for the scanning of up to 40 frames. To sum up, it is a film & slide scanner especially suitable for professional users.
10,000 dpi Resolution
With the advanced resolution, PrimeFilm XA Plus is capable of capturing and digitizing a sharp and vivid image from a bulk of films and slides.
Auto Focus
With this unique built in feature, auto focus applies to each image, providing optimal clarity and sharpness in your scans.
Auto Filmstrip & Roll Film Scanning Optimization of Scanning Speed
Batch Scans uncut roll film up to 40 frames or one filmstrip with 3 frames or more, gristly craze your workflow, freeing you up for other tasks.
Enhanced Image Quality
Keep the original raw image data in DNG format. Professional users can get their preferred image by post-processing from the raw image without any distortion in advance.
CyberViewX - Pacific Image Electronics Exclusive
*Tip：Please install the software before connecting to the computer.
- CyberView X - an exclusive software developed by Pacific Image Electronics for the scanners. It offers a plethora of unique features tailored to enhance the scanning experience. These include advanced functionalities mentioned:
- Gamma Curve Adjustment - Gamma curve adjustment enhances the brightness, contrast, and overall visual appeal of images by fine-tuning their light and dark tones. It helps achieve vibrant and balanced visuals, ensuring high-quality output that stands out.
- Image Adjustment - Providing adjustments for different tones and color temperatures, and allowing users to customize brightness, contrast, and saturation according to their preferences. Our software features preview windows for before-and-after comparisons, so users can see the visual impact of their adjustments before finalizing them.
- Fast & Quality Mode - Revolutionize your film scanning with cutting-edge software - CyberView X with Pacific Image Electronics. Experience lightning-fast speeds with Fast mode and exceptional imaging quality with Quality mode. Elevate your workflow today with the ultimate tool for film scanning enthusiasts.
Advanced Function Offered by CyberView X
- MagicTouch - Infrared dust and scratch removal technology eliminates flaws in film, such as dust or scratches, in the final image scan.
- Multipass Xposure - Optimal dynamic range technology scans each frame or slide multiple times to enhance the detail of dark area without sacrificing the bright area.
- Auto Color - Higher color accuracy, accurates color adjustment, resulting in vibrant images with optimal brightness, contrast and saturation.
- Digital Noise Reduction (DNR) - Isolate and manage noise/grain in both highlight and shadow areas without sacrificing image detail.
PrimeFilm XA Specifications
Scanning Media:
135 Mounted Slide, Filmstrip & Roll Film
135 Mounted Slide, Filmstrip & Roll Film
Resolution:
10,000 DPI
10,000 DPI
Dynamic Range:
4.2
4.2
Light Source:
White and Infrared LED Array
White and Infrared LED Array
Sensor:
Linear Array Color CCD
Linear Array Color CCD
Data Conversion:
48 Bits/px (color mode), 16 Bit/px (grayscale mode)
48 Bits/px (color mode), 16 Bit/px (grayscale mode)
Scanning Area:
24.3mm x 36.5mm (H x W)
24.3mm x 36.5mm (H x W)
Image File Format:
JPG, TIF , DNG
JPG, TIF , DNG
Power Supply:
AC 100-240V; 50/60 Hz Output: 12V DC / 1.5A
AC 100-240V; 50/60 Hz Output: 12V DC / 1.5A
Dimensions:
10.8 x 7.2 x 3.7 inch (27.4 x 18.3 x 9.4 cm)
10.8 x 7.2 x 3.7 inch (27.4 x 18.3 x 9.4 cm)
Net Weight:
4.9 lb (2.22kg)
4.9 lb (2.22kg)
OS:
Windows 7/8/10/11, Mac OS 10.13 (minimum)
Windows 7/8/10/11, Mac OS 10.13 (minimum)
Hardware Requirements:
RAM: 4GB (8GB or more recommended) / Hard Disk Free Space: 50 GB or more
RAM: 4GB (8GB or more recommended) / Hard Disk Free Space: 50 GB or more
| Scanning Media | 135 Mounted Slide, Filmstrip & Roll Film |
| Resolution | 10,000 DPI |
| Dynamic Range | 4.2 |
| Advanced Features | Auto Roll Film Scanning (up to 40 Frames) & Auto Focus |
| User friendly interface | • One Button Scan • Buttons for Ejecting, Reverseing and Forwarding • Viewing window |
| Light Source | White and Infrared LED Array |
| Sensor | Linear Array Color CCD |
| Data Conversion | 48 Bits per pixel (color mode) 16 Bits per pixel (grayscale mode) |
| Image File Format | JPG, TIF , DNG |
| Scanning Area | 24.3mm x 36.5mm (H x W) |
| Interface | USB 2.0 ONLY (USB 1.1 not supported) |
| Power Supply |
Image: AC 100-240V; 50/60 Hz Output: 12V DC / 1.5A |
| Accessories | • Wall-Mount Adapter • USB 2.0 Cable • Quick Installation Guide |
| Dimensions | 10.8 x 7.2 x 3.7 inch (27.4 x 18.3 x 9.4 cm) |
| Net Weight | 4.9 lb (2.22kg) |
| OS |
Windows 7/8/10/11 Mac OS 10.13 (minimum) |
| Hardware Requirements |
Windows Mac |
Please refer to the Quick Installation Quide before downloading:
/archive/scanner/PIE_QIG 2021 ENGLISH_2021_12_17.pdf
Open a Mac app from an unidentified developer – Apple Support (UK)
Driver for Mac OS 10.13 or higher
- Fixed the issue where the speed difference between Fast Mode and Quality Mode in Multipass Xposure was insignificant.
- Fixed the shading issue that occurred when using dpi settings other than optical resolution.
- Support Auto-update online functionality.
Auto-Update Functionality - Move Advanced Settings to the main screen.
- Bug Fix.
- Improve the precision and scanning speed of Auto crop when Multi Exposure is On.
- Rectify the issue of incorrect display sizes in Preview images.
- Address shadow issues in a few images when Multi Exposure is On.
- Fix the problem of images not being properly segmented in Half film mode.
- Resolve the software crash issue caused by using the DNG format.
- Support Half film.
- Improve the cropping issues that occur when using the CyberView UI for zooming, resizing, and rotating.
- Make the options in the Preference page clearer.
- Improve software stability.
- Rectify the slowdown issue when Multi Exposure is enabled.
- Correct the issue of frequent crashes in M1 & M2.
Driver for Windows 7/8/10/11 32 & 64 bit
- Fixed the issue where the speed difference between Fast Mode and Quality Mode in Multipass Xposure was insignificant.
- Fixed the shading issue that occurred when using dpi settings other than optical resolution.
- Support Auto-update online functionality.
Auto-Update Functionality - Move Advanced Settings to the main screen.
- Bug Fix.
- Improve the precision and scanning speed of Auto crop when Multi Exposure is On.
- Rectify the issue of incorrect display sizes in Preview images.
- Address shadow issues in a few images when Multi Exposure is On.
- Fix the problem of images not being properly segmented in Half film mode.
- Support Half film.
- Improve the cropping issues that occur when using the CyberView UI for zooming, resizing, and rotating.
- Make the options in the Preference page clearer.
- Improve software stability.
- Rectify the slowdown issue when Multi Exposure is enabled.
- Introduced the Faded Film Color Restoration feature to correct the color of film that has turned yellow due to its age.
- Added the DNG format, making the images more suitable for editing using Adobe software.
- Resolve the issue of incorrect positioning when using 'Image Adjustments' function with zoom In/Out.
